UPS Eaton 5P 1150VA

Characteristics Type: UPS Interactive (line-interactive) Purpose: For home, for computer Output Power Volt-amperes: 1150 VA Watts: 770 W Input Network Parameters Nominal Voltage: 230 V Minimum Voltage (for operation from a 220V network): 160 V (adjustable down to 150 V) Maximum Voltage (for operation from a 220V network): 294 V Frequency: 50/60 Hz (from 47 to 70 Hz) Frequency Deviation Range: ± 25% Output Parameters Nominal Voltage: 230 V (6/-10 %) Frequency: 50/60 Hz (/- 0.1 %) Efficiency at Full Load: 98 % Battery Parameters Autonomous Operation Time at Max Load: 4 min. Filtering and Protection Overload Protection: + Surge Protection: + Short Circuit Protection: + Connectors PC Connection Interface: DB9/RS-232 (COM), USB (cannot be used simultaneously) Input Connectors: (1) IEC-320-C14 Output Connectors: (6) IEC-320-C13 Physical Characteristics Width: 150 mm Height: 230 mm Depth: 345 mm Weight: 11.1 kg Additional Characteristics Pure Sine Wave Output 1 mini module for remote on/off and remote shutdown of outputs 1 connector for Network-MS, ModBus-MS, or Relay-MS cards ```
