Unmatched Performance

In the face of rapid technological changes, GIGABYTE always keeps an eye on the latest trends and offers its customers enhanced capabilities and cutting-edge technologies. GIGABYTE motherboards are equipped with upgraded power systems, the latest data storage standards, and excellent connectivity options to ensure optimal gaming performance.

Direct Digital Design of Graphics Cards

To ensure maximum Turbo Boost performance and overclocking of next-generation Intel processors, GIGABYTE AORUS series motherboards feature the best VRM design in history using the highest quality components.

• PCIe 4.0 x16 - Reinforced PCIe 4.0 x16 with reduced resistance.
• 2 M.2 PCIe 4.0 x4 Slots - M.2 PCIe 4.0 x4 slot with reduced resistance.
• DDR5 Overclocking up to 8000 and Beyond - AORUS offers a tested and proven platform with memory overclocking capabilities up to 8000 and beyond. For DDR5 XMP memory overclocking, all you need to do to achieve high memory performance is to ensure that the memory module supports XMP and that the XMP function is activated and enabled on the AORUS motherboard.

DDR5 Voltage Unlocking

DDR4 voltage is controlled by the motherboard with a wide range.

• Safe Mode - The motherboard supplies a fixed voltage of 5V to native DDR5 memory, while the built-in PMIC outputs lock 1.1V to the memory chip.
• Programmable Mode - GIGABYTE's exclusive design unlocks the protected Native DDR5 PMIC mode in programmable mode and allows for voltage management of Native DDR5 across a wide range.
• Exclusive GIGABYTE Circuitry Unlocks Native DDR5 Voltage Control - Converts a standard DDR5 memory module into an overclockable DDR5 memory module, enhancing DDR5 memory performance and overclocking capabilities.
• Support for All PMIC Manufacturers for Maximum Compatibility

Shielded Memory Routing

All memory routing is located under the internal layer of the printed circuit board, protected by a large ground layer to shield against external interference.

Optimized Impedance Topology

By optimizing the width, length, and style of memory traces from HPC simulation to real implementation, the overall impedance between the CPU memory controller and memory modules is reduced, allowing for higher DDR5 speeds.

Low Signal Loss Printed Circuit Board

To reduce signal loss within the printed circuit board and support high-speed DDR5 signal transmission, server-class material with medium or low loss has been selected.

DDR5 Automatic Booster

Automatically boost DDR5 memory frequency to 5000 MHz under high load with the push of a button.

DDR5 Memory Updates

GIGABYTE BIOS offers predefined profiles that can be easily modified to enhance performance. The profiles are based on a database created by testing each memory chip and PMIC manufacturer to optimize modules for full potential. This feature saves time on manual configuration of overclocked DDR5 memory kits.

Instant Memory Performance Boost

• Easily overclock native DDR5 and XMP 3.0 DDR5 memory to higher frequencies.
• No need to enter dozens of memory parameters such as frequency, voltage, and timings.
• Built-in database of various pre-configured profiles for different memory chip manufacturers.

XMP 3.0 User Profile

Define and create your own SPD profile for Native and XMP 3.0 memory modules or apply pre-configured profiles to the XMP 3.0 user profile. Two user profiles can be saved, loaded locally, or from/to an external storage device. Two empty SPD profiles can be defined by users and transferred to the next computer.

Transferring DDR5 XMP Booster Profiles to XMP 3.0 User Profile

Quickly model memory performance based on user-defined input frequencies and synchronization parameters. The save and load profile feature allows for online sharing of memory parameters.

PCIe 4.0 x4 M.2

AORUS motherboards offer industry-leading compatibility with NVMe drives for users who require high capacity and seek the best performance. Upgrading to the latest Gen4 solid-state drive delivers performance up to 7000 MB/s, which is twice as fast as PCIe 3.0 SSDs.

GIGABYTE PerfDrive

The PerfDrive technology combines several exclusive BIOS settings from GIGABYTE, allowing users to easily balance between different levels of performance, power consumption, and temperature according to their needs when using Intel Core 13th generation processors.

Max Turbo

The Max Turbo technology allows Intel Core 13th generation processors to run at maximum speed in Turbo Boost mode.

Optimization

The optimization mode allows the Intel 13th generation processor to balance between high performance and low temperature.

Specification Enhancement

The Spec Enhance mode allows the Intel 13th generation CPU to operate at high performance at lower temperatures.

E-Core Disable

The E-Core Disable mode allocates CPU resources exclusively to the P-core to enhance gaming performance while reducing overall power consumption of the processors.

Excellent Thermal Design

The unmatched performance of GIGABYTE motherboards is guaranteed by an innovative and optimized thermal design that ensures maximum stability of the CPU, chipset, solid-state drive, and low temperatures under full load in applications and games.

Thermal Design

• Integrated I/O Shield
• Thermal Pad 5W/mK
• Extended Heatsinks
• 10-layer and 2x copper printed circuit board
• Multilayer PCH and M.2 Heatsink
• Thermal Backplate

3% Cooler Through Implementation

The use of 2x copper in the internal layer of the printed circuit board reduces component temperatures by at least 3%, transforming the PCB into a super-thin copper heatsink of PCB size for effective heat dissipation from components due to high thermal conductivity and low impedance.

Smart Fan 6

Smart Fan 6 features several unique cooling functions that ensure the gaming PC maintains its performance while remaining cool and quiet. Multiple fan headers can support PWM/constant fan and pump, and users can easily define the curve of each fan based on various temperature sensors across the board using an intuitive user interface.

High Current Support

Each fan header supports PWM fan and DC fan, as well as a water cooling pump with a power of up to 24W (12V x 2A) with overcurrent protection.

Precise Control

Multiple temperature/speed control points for accurate fan curve.

Dual Curve Mode

Dual slope/stair mode for different user scenarios.

Fan Stop

The fan can completely stop below a user-defined temperature point.

Improved Fan Curve Interface

We have increased the number of control points from 5 to 7 and expanded the fan speed graph for more precise and easier fan curve control.

Dual Slope/Stair Graph Mode

The fan curve can be quickly switched using Slope and Stair modes for different user scenarios. Slope is the traditional and intuitive linear fan speed curve. With the newly added non-linear Stair mode, the fan maintains the same speed between defined temperature intervals.

Manual Input

For advanced users, we provide the option for manual fan speed input for more precise control.

EZ Tuning

You can set 4 EZ Tuning points with approximate temperature/fan speed values, and Smart Fan 6 can quickly generate the fan rotation curve.

Fan Curve Profile

The fan curve profile can be saved in the BIOS firmware, and the profile will be retained after a BIOS update.

Connectivity

GIGABYTE motherboards provide maximum data transfer speeds through next-generation networking, data storage, and wireless Wi-Fi connectivity.

802.11ax Wi-Fi 6E

The latest wireless solution 802.11ax Wi-Fi 6E with a new dedicated 6GHz band delivers gigabit wireless performance, smooth video streaming, better gaming experience, fewer connection dropouts, and speeds up to 2.4Gbps. Additionally, Bluetooth 5 offers 4 times the range compared to BT 4.2 and faster data transfer.

Smart Antenna

2x signal level compared to traditional antenna design. AORUS antenna with smart antenna function for the best Wi-Fi signal transmission.

Wi-Fi 6E Provides the Best Virtual Reality Experience!

Wi-Fi 6E offers higher Wi-Fi speeds, lower latency, and longer battery life for virtual reality devices, meaning wireless streaming of VR games from PC to VR device is much smoother and has higher video quality.

Wi-Fi 6E Compared to Wi-Fi 5 Provides

• 40% higher speed for smoother gaming/streaming
• 50% higher resolution for gaming-related content
• Longer battery life for virtual reality devices
• Twice as fast as ever

2.5G LAN Implementation

2.5 GbE network connectivity provides at least 2 times the data transfer speed compared to standard 1GbE networks, making it ideal for gamers seeking the ultimate online gaming experience.

Multi-Gigabit (10/100/1000/2500 Mbps) Ethernet RJ-45

Future-proof connectivity - rear USB 3.2 Gen 2 Type-C port. The built-in Intel USB 3.2 Gen 2 host controller provides USB 3.2 Gen 2 port speeds of up to 10Gbps. With double the bandwidth compared to the previous generation, and backward compatibility with USB 2.0 and USB 3.2 Gen 1, the significantly improved USB 3.2 Gen 2 protocol is available through the new reversible USB Type-C connector and traditional USB Type-A connector for better compatibility with a wider range of devices.

Front USB Type-C Connector

AORUS motherboards equipped with next-generation interfaces already support future-proof cases. The built-in USB Type-C connector for USB 3.2 Gen 1 provides convenient access for connecting a USB 3.2 Gen 1 drive or charging a new mobile device.

High-Quality Built-in Audio System

Delivers high resolution and sound expansion for the most realistic sound effects for professional gamers.

Customization

GIGABYTE motherboards come with useful and intuitive software that helps users manage every aspect of the motherboard's operation, as well as allowing them to customize lighting effects to highlight their individuality and showcase their unique style.

User-Friendly Interface

In EASY MODE, important hardware information is displayed on a single page, including CPU frequency, memory, storage, and fans.

Favorites

Add frequently used items to the "Favorites" menu for quick access.

Storage Information

Displays information about all types of storage devices, including SATA, PCIe, and M.2 interface.

Change Log

Lists all changes before saving and exiting the BIOS. Quick overview of overall setting modifications.

Intuitive Load Line Curve

Visual representation of each load line calibration parameter as an intuitive curve.

GIGABYTE Control Center

GIGABYTE Control Center (GCC) is unified software for all supported GIGABYTE products. It features a new intuitive user interface for managing all key functions.

• Single software platform for all supported GIGABYTE products
• Intuitive user interface for ease of use
• Modular control components only for installed hardware
• Automatic update feature to keep the system up to date and support future products

Multi-Function Button

A multi-function reset button that can be reassigned to another function in the BIOS for various user scenarios.

RGB Switch

Turn off all lighting effects on the motherboard.

Direct-To-BIOS

Boot directly into the BIOS menu without pressing any keys on the keyboard.

Safe Mode

Enter BIOS safe mode to change a specific option without losing other BIOS settings.

Ultra Durable

The GIGABYTE Ultra Durable design ensures product longevity and high manufacturing quality. GIGABYTE motherboards use the best components and reinforce all slots to make each one reliable and durable.

Q-Flash Plus

With GIGABYTE Q-Flash Plus, you don't need to install a CPU, memory, or graphics card, nor enter the BIOS menu to flash the BIOS. Just download and save the new BIOS file (renaming it to gigabyte.bin) on a USB drive, then press the dedicated Q-Flash Plus button - and you're ready to go!

1. Connect the 24-pin and 8-pin power cables to the motherboard.
2. Download the motherboard BIOS file, rename it to "gigabyte.bin", save it on a USB drive, and connect the USB drive to the Q-Flash USB port.
3. Press the Q-Flash Plus button, and the motherboard will begin the automatic BIOS update.
